OEM 404.867.0010 Quality Valeo Wiper Motors with Automotive And Industrial Applications

LC-ZD1013

Product Introduction:

Inspired by the original Nidec-Valeo motor design, this high-performance DC motor is available in 12V, 24V, and 48V ,ensuring broad compatibility with automotive and industrial applications. The motor features a robust construction with optional plastic or copper gears, allowing customers to choose between cost efficiency (plastic) or enhanced durability (copper) based on their needs.

We want to make the dc wiper motor smooth operation, low noise, and long service life, this motor is ideal for wiper systems, HVAC actuators, and small machinery.It is a small dc gear motor, efficient power consumption, and weather-resistant housing (IP54-rated) make it suitable for harsh environments. Customization options include gear materials, voltage variants, and mounting shafts and angles, ensuring the wiper motor run well.

Model:
LC-ZD1013

Availability:

Quantity:



Inquire Add to Basket

12V 24V and 48V motor dc wiper motor wiper systems small dc gear motor industrial

Product Description

FAQ

Parameter	Specification
Model Number	404.867.0010 (24V version)
Voltage Options	12V / 24V / 48V DC
Rated Speed	35 ±5 RPM
Gear Options	Plastic / Copper (Brass)
Rated Torque	30nm
Power Consumption	50w
Current Draw
Rotation Direction	CW/CCW (Selectable)
Protection Rating	IP54 (Dust & Splash Proof)
Operating Temp	-30°C to +85°C
Housing Material	Reinforced ABS/PA6
Shaft Material	Stainless Steel
Gear Material	Plastic (Standard) / Copper (Optional)
Noise Level	< [X] dB (Quiet Operation)
Connector Type	Accoring to your choose
Certifications	RoHS, CE

Product Advantage:

Valeo-Style DC Motor (12V/24V/48V) - Key Advantages

1.Multi-Voltage Compatibility

Available in 12V, 24V and 48V configurations to meet diverse application requirements across automotive and industrial sectors.

2.Premium Gear Options

Offers both plastic and copper gear versions:

Plastic gears: Cost-effective solution with good wear resistance

Copper gears: Superior durability,life cycle is longer than plastic,at the same time,it is more expensive

3.Authentic Performance

ensuring OEM-level quality and reliability.

4.Optimized Power Efficiency

The motor has excellent torque output while maintaining low power consumption.

5.Customization Capabilities

Flexible solutions available for:Voltage specifications,Gear materials,Mounting configurations,Speed and torque requirements

Competitive Pricing

Offers cost-effective alternative to original parts without compromising quality.

This high-performance DC motor combines the proven Valeo design with modern manufacturing techniques to deliver exceptional value for both replacement and OEM applications.

Product Uses

Compatible Applications:

1.Valeo Wiper Motor Replacement

2.Dairy Farm Feed Machines

3.Commercial Coffee Machines,Food processing conveyor motors

4.Garage Door Openers

5.Industrial Automation Equipment:Packaging equipment,Garage door openers,Textile machinery components

6.Small Machinery & Electric Vehicles:Agricultural equipment,Electric mobility devices,Medical equipment drives

1. Can Valeo wiper motors be used in industrial equipment?

Yes! Valeo wiper motors are not only for automotive use but also suitable for industrial machinery, agricultural vehicles, marine applications, and heavy-duty equipment requiring reliable wiping systems.

2. How do I choose the right Valeo wiper motor for my industrial machine?

(1) Check voltage requirements (12V/24V DC).

(2) Match torque/speed specs to your application.

(3) Verify mounting type (e.g., screw-on, gear-driven).

3. Why is my Valeo wiper motor overheating?

Common causes:

Excessive load (e.g., frozen wiper blades).

Incorrect voltage supply.

Worn gears/bearings.
