LCEQ11.01
LICN
| Availability: | |
|---|---|
| Quantity: | |
| Parameter | Specification |
|---|---|
| Model Reference | 404.868 / DCK31 |
| Rated Voltage | 24 V DC |
| No-Load Speed | 21 rpm |
| Rated Torque | 4 Nm |
| Rated Power | 7.79 W |
| Rated Current | 2 A |
| Motor Type | Brushed DC, permanent magnet |
| Gearhead Type | Worm gear |
| Gear Ratio | 69:1 |
| Gearing Side | Right-hand |
Our series gear motors support a full range of different models and customized parameters, all specifications can be manufactured as your requirements.
Output and power transmission are identical to the original Valeo part. The motor is designed as a 1:1 replacement — same mounting hole pattern, same shaft dimensions, same wiping angle and park position — eliminating the risk of incorrect installation or linkage mismatch.
Manufactured from 100% original equipment-grade materials, including a permanent-magnet brushed motor and a precision worm gearhead with a 69:1 reduction ratio. The steel output shaft and reinforced housing are engineered for continuous duty in high-vibration environments.
Every unit is subjected to the same validation regime as the OE part, including test runs exceeding 1.5 million wiping cycles, with continuous monitoring of wiping angle, power draw, tension, and operating temperature. Functional testing is carried out across defined climate profiles, including winter and high-humidity conditions.
The worm gear design and precision manufacturing tolerances minimize vibration and operating noise. This is particularly important in modern commercial vehicles where cab noise levels are tightly controlled. The permanent-magnet motor construction also ensures consistent torque output across the service life.
This motor family is specified as original equipment across major European truck and bus platforms, including MAN TGA/TGL/TGS, Mercedes Actros/Atego, DAF 95/XF/85, and other heavy-duty applications. It is equally suited to industrial wiping systems and specialty vehicle installations.
Commercial vehicle windshield wiper systems (trucks, buses, coaches),
industrial wiping equipment,
specialty vehicle wiper assemblies.
Q1: What is the difference between this aftermarket part and the genuine Valeo 404.868?
A: Aftermarket parts are produced by independent manufacturers and are designed to fit and function like the original part, but are not sold under the original brand name. The key difference lies in branding and price — the aftermarket version offers equivalent form, fit, and function at a more competitive price point, without the premium associated with the OEM brand label.
Q2: Will this part fit my equipment?
A: This motor is designed as a drop-in replacement for the Valeo 404.868 / DCK31. Key fitment specifications include:
Rated voltage: 24V DC
No-load speed: 21–22 rpm
Rated torque: 4 Nm
Gearing: right side
Bolt hole circle: 50.8 mm
Hole centre distance: 43.5 mm
Shaft diameter: 10 mm
Shaft length: 84 mm
If your original unit matches these specifications, this replacement will fit directly.
Q3: What quality standards does this part meet?
A: Our aftermarket replacement is manufactured under quality management systems aligned with automotive industry standards. Each unit undergoes functional testing for voltage, torque, speed, and dimensional accuracy before dispatch.
Q4: Do you ship internationally?
A: Yes. We serve customers in the aftermarket globally. Shipping options and lead times vary by destination. Please contact our sales team for a shipping quote to your location.
| Feature | Our Product |
Performance | OEM-Spec or Better |
Fitment | 100% Direct Fit |
Durability | High (Corrosion-Resistant) |
Price | Highly Competitive |
| Customization | Available (OEM/ODM) |
| Supply | Expert Technical |
| Support Chain | Direct from Factory |
LICN is a specialized manufacturer based in China’s heartland of auto parts, Ruian, Zhejiang. We are dedicated to the research, development, and production of high-performance automotive motors. Our state-of-the-art facility is equipped with advanced testing equipment, and every unit undergoes strict quality control inspections before leaving our factory. We are not just a supplier; we are your strategic partner for quality, reliability, and growth in the automotive aftermarket.
Ready to experience the perfect blend of quality, value, and service? Contact our expert team today for a personalized quote or to discuss your customization needs.
