| Quantity: | |
|---|---|
| Parameter | OEM/Model Angle | Applications | |
V | 12/24 | 60 degrees 70 degrees 90 degrees 105 degrees 120 degrees 165 degrees | Wode tractor Zhonglian Agricultural Equipment Export tractors for foreign trade |
W | 30 | 165 degrees and 180 degrees | |
RPM.L | 40±5 | ||
RPM.H | 55±5 | ||
| N.M | ≥12 | ||
Parameter | Specification |
Power Rating | 30W |
Voltage | 12V/24V DC |
Speed Options | High/Low speed |
Wiping Angle | Adjustable (60°-180°) |
Rotation | Bidirectional (LH/RH available) |
Protection Class | IP65 (Dustproof and water-resistant) |
Operating Temperature | -30°C to +80°C |
Duty Cycle | Continuous operation |
Material | Durable metal housing |
Certifications | CE, RoHS compliant |
Applications | Tractors, agricultural machinery, off-road vehicles |
Lifespan | 50,000+ cycles |
Product Advantage:
1.Specifically engineered for agricultural vehicles, the 30W DOGA wiper motor offers dual-speed functionality (high/low), ensuring adaptable performance across all weather conditions. Its adjustable wiping arm, ranging from 60° to 180°, ensures optimal coverage tailored to various windshield sizes.
2.Constructed with heavy-duty materials, this motor is highly resistant to dust, moisture, and vibrations, making it exceptionally suitable for demanding agricultural environments. The precision-engineered gear system guarantees smooth and reliable operation while minimizing maintenance requirements.
3.Its compact design and straightforward installation process make it an ideal choice for tractors, harvesters, and off-road equipment. The quality of this wiper motor ensures long-term durability and consistent performance throughout multiple seasons.
Product Uses
30W DOGA Wiper Motor - Application Scenarios
1.Tractors & Agricultural Vehicles
Specially designed for rugged farm use. The dual-speed (high/low) operation adapts to varying weather conditions, while the adjustable 60°-180° wiping angle fits different tractor windshield sizes.
2.Harvesters & Combine Machines
Maintains optimal visibility during long harvesting operations. The low-speed setting provides gentle wiping for light debris, while high-speed effectively clears heavy mud or crop residues.
3.Forestry & Off-Road Equipment
The motor's sealed design protects against wood chips, dirt and moisture, while the robust gearbox handles constant vibration on rough terrain.
4.Agricultural Transport Vehicles
Provides reliable performance in grain trucks and livestock transporters. The dual-speed function allows drivers to switch between light maintenance wiping and intensive cleaning during dusty operations or rainstorms.
5.Irrigation System Control Units
Used in some automated irrigation setups where moisture-resistant wiper mechanisms are needed to protect control panel view ports from water splashes and mineral deposits.
6.Poultry/Livestock Farm Vehicles
Special ventilation-equipped versions available for use in ammonia-rich environments of large animal farms, preventing motor corrosion from constant exposure to manure gases.
