Robust 24V DC Permanent Magnet Motor – Delivers consistent power output of 50–80W, specifically engineered for heavy-duty commercial vehicle applications.
High Torque Performance – Provides ≥30 N.m of torque to effectively clear rain, snow, and debris from large windshield surfaces.
Dual Speed + Intermittent Function – Multiple operating modes allow drivers to adjust wiper speed according to real-time weather conditions.
Automatic Park Return Mechanism – Built-in park switch ensures the wiper automatically returns to the correct stowed position when turned off.
Parameter | Details | Description |
Model Number | LC-ZD1022L | Unique identifier for this wiper motor unit. |
OEM Cross-Reference | F006B20106 | Directly replaces the original Land Rover part number. |
Voltage | 24V | Compatible with a wide range of Land Rover electrical systems. |
Power | 50W | Provides sufficient power for smooth, efficient wiper operation. |
Low Speed (RPM.L) | 35±5 | Revolutions per minute for low speed wiping, ensuring control in light rain. |
High Speed (RPM.H) | 45±5 | Revolutions per minute for high-speed wiping, clearing heavy downpours quickly. |
Torque (N.M) | 35 | High torque output to overcome resistance from heavy snow or debris on the windshield. |
Core Advantage | OEM-Equivalent Quality | Manufactured to meet or exceed original equipment specifications for fit, form, and function. |
Long Operational Life – Rated for over 5 million wipe cycles, minimizing replacement frequency and reducing total cost of ownership.
Wide Temperature Tolerance – Operates reliably from –40°C to +85°C, ensuring dependable performance in both freezing winters and hot summer conditions.
Universal Compatibility – Suitable for a wide range of 24V commercial vehicle platforms.
Sealed Construction – IP54 to IP67 protection rating (depending on manufacturing specification), designed to withstand moisture, dust, and temperature extremes.
Note: This list model the most common applications. For other models or if you are unsure, please contact us with your VIN (Vehicle Identification Number) for a 100% compatibility check.
